JWE-R17
1.23kW ACDC Power Module for Electric Vehicle
| Input Voltage Range | 198~242Vac, 1Ø 2W + PE (220Vac -20% ~ 220Vac +20%) |
|---|---|
| Output Voltage Range | 40~82Vdc |
| Rated Power | 1.23kW |
| Efficiency | ≥89% (Max) |
| Dimension / Weight | 110mm(H) x 250mm(W) x 150mm(D) / Kg |
